Reverse Osmosis Plant

Reverse Osmosis Plant is widely used for removal of dissolve chemical impurities from brackish & seawater. Reverse osmosis is the process of forcing a solvent from a region of high dissolve solids concentration through a membrane to a region of low dissolved solids concentration by applying a pressure in excess of the osmotic pressure.The semi permeable membranes used for reverse osmosis have a dense polymer barrier layer in which separation takes place.

Shubham Inc RO Plants are designed for a variety of industrial & commercial applications requiring high quality equipment with a fast delivery and competitive price. These pre-engineered, pre-assembled and factory tested units minimize installation and start-up time. With simple utility connections and easy to set up controls, the unit is ready for quick on-line service. The control system is an advanced microprocessor based system that is very easy to use.

Shubham Inc RO Plants are available in flow rates from 0.25 M3/hr. to 100 M3/hr. Using high quality 4 and 8 inch semipermeable membrane and equipments for variety of applications.

Working Principal

Reverse osmosis is water purification process in which pre-treated & filtered water is connected to the high-pressure pump where pressure is developed and fed to the RO membranes.Reverse Osmosis membranes work on the Cross flow Filtration method where the salts get rejected partially and deliver pure water. Purified water is referred to as product and waste water is referred to as concentrate or reject. The percent of water delivered as product is called the recovery. The ratio of recovery & output parameters depend upon the feed water quality, type of membrane, temperature and total RO unit design considerations.

Technical Specifications

Flow	:	0.25M3/Hr. – 50 M3/Hr.
Inlet TDS	:	Up to 10000 Mg/L for brackish water up to 35000 Mg/L for Sea Water
Outlet TDS	:	98% Rejection
Flux Rate	:	Varies from 15 LMH to 30 LMH
Temperature	:	25˚ Celsius
Type of Membranes	:	Energy efficient Polyamide
SDI	:	< 3 at inlet
Controls	:	Microprocessor / PLC
Flow Monitoring	:	Rota meter / digital flow meters.
Pre filters	:	PP & SS with 5 Micron cartridges
High Pressure Pumps	:	Vertical inline SS 304 & 316
Pre Filter	:	Cartridge Filter of 5 Micron absolute
Membranes housing	:	FRP / SS
RO Skid	:	MSEP / SS

Salient features

• TFC RO Membranes ensure optimum water quality
• High pressure 316 stainless steel vertical multistage feed pump
• ASME Code FRP, RO pressure vessels with pressure relief protection
• UPVC low pressure feed, product and reject piping, 316L stainless steel high pressure piping
• Epoxy coated carbon steel / SS frames
• Dry contacts are provided for chemical feed, pre-treatment equipment, storage tank levels, and pressure switches
• All alarm and shut down conditions are indicated on the control interface.

Advantages

• User-friendly programmable controls
• High quality components ensure continuous, reliable operation
• Pre-engineered systems mean easy installation
• Clean-in-place connections maximize system availability
• Compact footprint saves valuable floor space
• Quick equipment delivery keeps project moving fast
• Easy to install and operate.
• Produces high quality Water
• Variety of cost effective standard models.

Applications

• Boiler water Treatment
• Cooling Tower Water Treatment
• Process Water
• Drinking Water
• Horticulture for high end crop
• Dialysis
• Laboratories
• Water For injection (WFI)
• Water for electrical conductor circuits
• Wastewater recycling
• Zero Liquid discharge system

Manufacturer - Supplier - Sewage Treatment plant - Gujarat India

Supplier and Manufacturer of Sewage Treatment Plant in Gujarat India

shubhm inc are supplier - manufacturer of sewage treatment plant,water treatment plant,RO Plant for all type of industries - government in Gujarat,India across the Ahmedabad,Surat,Rajkot and Baroda.

Industrial

 Sewage Treatment Plant:

We Shubham are largest Manufacturer Sewage Treatment Plant, Various industries generate Sewage from kitchen, administrative building, and Labor& staff colonies. It includes household waste liquid from toilets, baths, showers, kitchens, sinks and so forth that is disposed of via sewers.The objective of sewage treatment is to produce a disposable& reusable effluent.

Sewage treatment includes physical, chemical, and biological processes to remove soluble organic and inorganic impurities from domestic wastewater.

Industries can recycle treated sewage water for various application i.e.

A] Cooling tower make up
B] Boiler feed
C] Car & floor washing
D] Toilet flushes
E] Gardening application

Which substantially reduce their fresh water consumptions and contribute to environment.

Shubham offer varieties of Sewage Treatment Plant from underground to above ground and package to onsite installation with the single or combination of environment friendly technologies as per industries location and uses. Our STPs product ranges are as below: –

1] Above Ground Sewage Treatment Plant – Onsite
2] Under Ground Sewage Treatment Plant – Onsite
3] Modular Sewage Treatment Plant – Prefabricated

 Government and Municipal

 Sewage Treatment Plant

Sewage treatment plant India for municipal & government is a process of Sewage collection from city and other inhabited areas, through interconnected network of sewerage lines and disposalto centralize sewage treatment facility to protect public health and prevent diseaseas well as water pollution from sewage contaminants.

Apart from public health and pollution norms, STP facilities has also becoming new source of water which can be used for irrigation, horticulture, industrial and many other non-potable purpose. Recycling of sewage treated water directly reduce consumption of fresh water and help to come out from water scarcity problem.

Sewage treatment is the process of removing contaminants from domestic wastewater called “Sewage” coming from various part of city and inhabitant area, which includes physical, chemical and biological processes to produce an environmentally safe fluid waste stream (or treated effluent) and a solid waste (or treated sludge) suitable for disposal or reuse (usually as farm fertilizer).

Various technologies from Oxidation pond to Activated sludge process and advance MBBR to MBR process has been adopted by municipal and government bodies to provide effective treatment of domestic sewage water depending upon the uses of treated sewage water which formulate as sewage treatment plant india.

Shubham is a leading in sewage treatment plant india, EPC contractor; provide turnkey solution to municipal bodies from concept to design, supply, install, commissioned and operation & maintenance of Sewage Treatment facility with the combination of various technologies at the most comprehensive, cost-effective and reliable practices.

 Commercial

 Sewage Treatment Plant

Increasing scarcity of fresh water and environmental concerns drives wastewater reuse; more and more buildings are setting up sewage treatment plants for their needs.The green building movement also places an allowance on water conservation and recycling, along with energy savings.

Sewage is generated by institution and commercial establishments. It includes household waste liquid from toilets, baths, showers, kitchens, sinks and so forth that is disposed of via sewers.The objective of sewage treatment is to produce a disposable effluent which can be used for various applications from gardening to toilet flushing to car & floor washing and reduce the fresh water consumptions in building and institutions & sewage treatment plant ahmedabad.

At Shubham we provide sewage treatment plant ahmedabad, we understand these trends and work closely with our customers to meet their current and future needs.

Sewage treatment Plant is the process of removing contaminants from wastewater, including household sewage and runoff. It includes physical, chemical, and biological processes to remove physical, chemical and biological contaminants. Its objective is to produce an environmentally safe fluid waste stream and a solid waste suitable for disposal or reuse. With suitable technology, it is possible to re-use sewage effluent for drinking water, although this is usually only done in places with limited water supplies such as Ahmedabad Gujarat, India.

With Shubham INC. engineering expertise, profound design and construction capabilities we deliver the capability to Design, Construct, Install & commission plants of almost all capacities & technologies. It provides total wastewater treatment solutions to commercial institutions like Hotels, Hospitals, Shopping malls, IT Parks, Residential and other commercial complexes and sewage treatment plant ahmedabad.

Shubham Inc. is the leading water and waste water management company providing the most comprehensive water and waste water treatment systems and services for industrial, institutional and municipal customers. We are a reputed manufacturer, exporter, importer, supplier and trader of an exhaustive range of Water and Waste Water Treatment Products and Services such as Filtration Systems, Water Softening Systems, Sewage Treatment Plant, Water Treatment Plant, WTP, Well Water Treatment, River Water Treatment Plants industrial RO Plant , etc.

shubham inc use the best-in-class technology and cutting-edge tools to foster high-quality, sustainable, community-level water supply sewage treatment plant and industrial ro plant projects in gujarat, india across the ahmedabad, surat, rajkot and baroda.

shubham inc is a leading manufacturer of Sewage Treatment Plants for the industrial, Government and Municipal . With a decade old experience, shubham inc has successfully executed over 1000 installations in industries, Government, hotels, and Municipal  becoming a preferred supplier of Sewage Treatment Plants.

Bio Accelerator 360 Degree - Sewage Treatment Plant - MBBR Technology - STP

Bio-Accelerator 360°™

 Overview

Bio-Accelerator 360°™ is an advanced ‘plug and play’ MBBR (Moving bed bio Reactor) waste water treatment system featuring the submerged bio media. The Bio-Accelerator 360°™ is engineered to provide a high quality effluent, treated to pollution control board standards and suitable for a variety of reuse applications.

On the contrary to Pre assembled and modular STP, above ground On-site Bio-Accelerator 360°™ Sewage Treatment plant is flexible is design and construction.

Bioreactor, settling tanks & chlorine contact tanks are built in concrete tanks open topped with safety railings around access points. MEP (Mechanical, Electrical and Piping)  equipment’s i.e. sewage feed pumps, MBBR & tube settler media, RAS Pump, aeration blower& fine diffuse are supplied in loose form and dosing systems, Tertiary system, monitoring and control systems are skid mounted make installation very flexible as per site conditions.

The factory fitted and tested equipment’s along with semi / Automatic control panel includes full process Monitoring and data logging functions.

Treatment Process

Bio-Accelerator 360°™ On-site sewage treatment plant is a fully/Semi Automated waste water treatment system incorporating the following process stages:

1. Inlet screening
2. Primary / Anoxic tank – DE nitrification (Optional)
3. Aeration Tank with UV resistance bio media.
4. Secondary Settling Tank with PP tube media.
5. Chlorine Contact tank
6. RAS and sludge removal
7. Tertiary Treatment for polishing

All tanks are built in concert and equipment installation is done on-site.

MBBR -Moving Bed Bio Reactor Latest Technology for STP

 Working Principal

The heart of the Bio-Accelerator 360°™ is design of aeration tank and bio-media as it removes organic impurities through a biological process. The biological process involves growing millions of bacteria that eat up organic impurities. Thousands of Virgin PP media pieces provide larger surface area for quick bacterial growth. Bacteria get attached to the surface of media-piece sand gets detached after attaining mass and age, giving room to other bacteria to grow at the surface of the media.
Continuous and right supply of air through Diffusers provides mobility to the media and the sewage, for accelerated biological growth of bacteria… and provides vital oxygen for bacterial growth. The Accelerator 360°™ technology ensures that Food and Mass Ratio is continuously maintained uninterruptedly throughout the process for desired level of Mixed Liquor Suspended Solids (MLSS) which is critical for subsequent processes.
The mixed-liquor largely free of organic impurities, with controlled levels of BOD and COD, overflows to the next chamber for settling and filtration process.
And all institution and industrial premises which have laundry water facilities. We at Shubham provided optimum use of treated laundry water with economical and innovative technologies.


Flow : 10 to 5000 M3/day and more
Pre Screening : 5 MM Vertical screen
Technology : Attached bio Growth
Hydraulic retention time in AT : 3 to 6 hrs.
Carrier filling degree : 20 – 60 %
Organic load range : 1 – 20 kgBOD/(m3*d)
Settling process : Tube settling
Sludge recirculation rate : 0 – 15 %
Tank MOC : Concrete
Polishing Treatment : Sand & Carbon Filters
Controls : Electrical / Microprocessor / PLC

Salient Features

• Plug and play packaged system
• All tank in civil with flexible positioning
• Automatic / Manual screen
• UV resistance MBBR Media
• Proven design
• Fully Factory Tested equipment’s
• Systems available from 10 – 5000 kl/dayand more
• Compact and easy to build anywhere.
• Standard on-site assembly suitable for concert tanks.
• Fully / semi-automatic controls

 Benefits

• Concert tank design enhance longevity
• Flexible Positing of tanks
• Can be built in one, two or three story.
• Small footprints reduce land use.
• Expandable and flexible designs
• Completely above ground installation.
• Easy to install &expand.
• High removal efficiency for nitrogen, BOD & COD,
• Treated Water reuse in irrigation and grey water applications.
• Minimum maintenance requirements.
• Full technical, installation and operation support from trained and experienced Shubham Team.
• Proven Technology with reliable performance.
• Reuse of Wastewater in gardening application.

Contact Shubham INC. Representative for further details on info@shubhamindia.com
visit : - www.shubhamindia.com

Manufacturer – Supplier – Sewage Treatment plant – Gujarat India

Sewage treatment plant in Gujarat – India

We at Shubham, Manufacturer – Supplier Sewage Treatment Plant ,we offer variety of sewage treatment plant from conventional to innovative technology and modular to onsite treatment plant as per customer’s relevance and area availability as in Ahmedabad, Surat, Rajkot, Baroda, Gujarat and across the India.

Shubham Inc.has expanded its foray into Water and Sewage Water Treatment Plants. Shubham‘s product range mainly split into two market vertical Water Treatment & Waste water Treatment.



What Is Sewage Treatment Plant ?

Sewage treatment Plant is the process of removing contaminants from wastewater, including household sewage and runoff. It includes physical, chemical, and biological processes to remove physical, chemical and biological contaminants. Its objective is to produce an environmentally safe fluid waste stream and a solid waste suitable for disposal or reuse. With suitable technology, it is possible to re-use sewage effluent for drinking water, although this is usually only done in places with limited water supplies such as Ahmedabad Gujarat, India.

Shubham India are supplier and manufacturer of Sewage Treatment Plant and Water Treatment Plant products such as Industrial RO Plant, Ultra filtration Plant, Pressure Sand Filter, Multi Grade Sand Filter, Dual media Filter, Side stream filters, Water Softener Plant, Demineralization, Mix bed Unit, RO Plant and many more whereas Waste water treatment product range consist of conventional Sewage Treatment plant, Advance Bio- Accelerator 360[ MBBR ], Bio Hybrid [MBR], Package Sewage Treatment Plant, Underground FRP Sewage Treatment Plant, Septic Tanks, Grey Water Treatment, Laundry Water Treatment, ultra-Latest Electra-rapid (electro Coagulation), plant as an end-to-end service provider.

We use the best-in-class technology and cutting-edge tools to foster high-quality, sustainable, community-level water supply projects in Gujarat, India across the Ahmedabad, Surat, Rajkot and Baroda.

Sewage Treatment Plant

The Sewage Treatment Plant process is similar to the way that a Septic Tank works but mechanical components provide a process to help break down solids to produce a cleaner, more environmentally friendly effluent.
Combined sewage contain various biological impurities, are fed into the primary settlement tank where solids and liquids separate and the liquor flows into the aeration chamber. In the chamber, a surface aerator or diffuser aerator infuse air and oxygen to the waste and encourages good bacteria to digest the organic matter, breaking it down and purifying it.As it leaves the final chamber known as the settling chamber, the effluent is typically 95% clean and ready for discharge into local watercourses, ditches or land drainage systems, subject to consent by the Environment Agency.
We at Shubham, Supplier Sewage Treatment Plant ,we offer variety of sewage treatment plant from conventional to innovative technology and modular to onsite treatment plant as per customer’s relevance and area availability as in Ahmedabad, Surat, Rajkot, Baroda, Gujarat and across the India.

Modular Sewage treatment Plant

Shubham’s(MD series) of Modular sewage treatment Plant is a closed steel module with three chambers — aeration, settling and discharge-disinfection. Each chamber features the necessary access and inspection registers.This modular construction allows the increase of the processing capacity by placing more plants in parallel.All the instruments and control elements of the plant are housed inside an anti-vandal cabinet. These plants do not generate noise &odors due to their closed modular construction. Thedesign of these plants allows installation in a single day.

Onsite – Above Ground

Onsite wastewater treatment is becoming the preferred treatment method over centralized treatment plants.Shubham’s(AG Series) of onsite above ground sewage treatment plantis a single-built concrete module contains aeration, settling and disinfection chambers inside in a closed concrete pit.
This concrete construction does not have any limitation of flow and capacity and can be built from 10 KL to 2 MLD. Separate plant room is constructed to house all the instruments and control elements. These plants has low life cycle cost and provide flexibility to build tanks in shape and dimension.
Onsite above ground STP Eliminates the long distance transport of wastewater to treatment plants and purified water back to the point of origin

Onsite – Under Ground

Land constraint in developing cities has always been problematic mainly due to the vertical growth, high population and density.It constantly faces the challenge of planning their land use to overcome their land constraints for developing infrastructure facilities in limited area.

Shubham’s(UG Series)of Onsite below ground Sewage Treatment Plant is an effective solution, where space is major concern for any developer and Infrastructure Company. We provide customize solution and design for maximum use of land with the effective treatment of domestic sewage.

Our below ground sewage treatment plant can be built below the road, basement & parking area, gardening and consume only unused area of total land.

kaushik basu quotes

A small tip for the sake of our environment.When
you leave a meeting take with you the bottle of water you just opened to the next meeting

- KAUSHIK BASU,

chief economist to World Bank,

on being environmentally

conscious

MBBR - Moving Bed Bio Reactor | Latest Technology for Sewage Treatment Plant

 MBBR - Moving Bed Bio Reactor | Latest Technology for STP

Bio-Accelerator 360°™ is an advanced ‘plug and play’ MBBR (Moving bed bio Reactor) waste water treatment system featuring the submerged bio media. The Bio-Accelerator 360°™ is engineered to provide a high quality effluent, treated to pollution control board standards and suitable for a variety of reuse applications.

MBBR are latest technology for Sewage Treatment plant manufacturer and supplier by shubham Inc in gujarat, ahmedabad,surat,rajkot,baroda.

On the contrary to Pre assembled and modular STP, above ground On-site Bio-Accelerator 360°™ Sewage Treatment plant is flexible is design and construction.

Bioreactor, settling tanks & chlorine contact tanks are built in concrete tanks open topped with safety railings around access points. MEP (Mechanical, Electrical and Piping)  equipment’s i.e. sewage feed pumps, MBBR & tube settler media, RAS Pump, aeration blower& fine diffuse are supplied in loose form and dosing systems, Tertiary system, monitoring and control systems are skid mounted make installation very flexible as per site conditions.

The factory fitted and tested equipment’s along with semi / Automatic control panel includes full process Monitoring and data logging functions.

Treatment Process

Bio-Accelerator 360°™ On-site sewage treatment plant is a fully/Semi Automated waste water treatment system incorporating the following process stages:

1. Inlet screening
2. Primary / Anoxic tank – DE nitrification (Optional)
3. Aeration Tank with UV resistance bio media.
4. Secondary Settling Tank with PP tube media.
5. Chlorine Contact tank
6. RAS and sludge removal
7. Tertiary Treatment for polishing

All tanks are built in concert and equipment installation is done on-site.

Working Principal

The heart of the Bio-Accelerator 360°™ is design of aeration tank and bio-media as it removes organic impurities through a biological process. The biological process involves growing millions of bacteria that eat up organic impurities. Thousands of Virgin PP media pieces provide larger surface area for quick bacterial growth. Bacteria get attached to the surface of media-piece sand gets detached after attaining mass and age, giving room to other bacteria to grow at the surface of the media.

Continuous and right supply of air through Diffusers provides mobility to the media and the sewage, for accelerated biological growth of bacteria… and provides vital oxygen for bacterial growth. The Accelerator 360°™ technology ensures that Food and Mass Ratio is continuously maintained uninterruptedly throughout the process for desired level of Mixed Liquor Suspended Solids (MLSS) which is critical for subsequent processes.

The mixed-liquor largely free of organic impurities, with controlled levels of BOD and COD, overflows to the next chamber for settling and filtration process.

And all institution and industrial premises which have laundry water facilities. We at Shubham provided optimum use of treated laundry water with economical and innovative technologies.

Onsite Sewage Treatment Plants are ideal for the following applications:

• Housing Project.
• Schools & hostels.
• Industrial Office &Parks.
• Small Communities.
• Recreational camps & travels trailer parks.
• Shopping Centres.
• Restaurants.
• Resorts, Golf Courses and country clubs.
• Rural Area Schools
• Hospitals

For Details Log on to : shubhamindia.com

Industrial RO Plant in Ahmedabad Gujarat

Industrial RO (Reverse Osmosis) Plant in Ahmedabad

Industrial RO (Reverse Osmosis) Plant is widely used for removal of dissolve chemical impurities from brackish & seawater. Reverse osmosis is the process of forcing a solvent from a region of high dissolve solids concentration through a membrane to a region of low dissolve solids concentration by applying a pressure in excess of the osmotic pressure.The semi permeable membranes used for reverse osmosis have a dense polymer barrier layer in which separation takes place.

Shubham inc, Industrial RO Plant are designed for a variety of industrial and commercial applications requiring high quality  Industrial equipment in Ahmedabad, Gujarat.

A reverse osmosis plant (RO) is a manufacturing plant where the process of reverse osmosis takes place. An average modern reverse osmosis plant needs six kilowatt-hours of electricity to desalinate one cubic meter of water.[1] The process also results in an amount of salty briny waste. The challenge for these plants is to find ways to reduce energy consumption, use sustainable energy sources, improve the process of desalination and to innovate in the area of waste management to deal with the waste. Self-contained water treatment plants using reverse osmosis, called reverse osmosis water purification units, are normally used in a military context.

Shubham Industrial RO Plants are designed for a variety of industrial & commercial applications requiring high quality equipment with a fast delivery and competitive price. These pre-engineered, pre-assembled and factory tested units minimize installation and start-up time. With simple utility connections and easy to set up controls, the unit is ready for quick on-line service. The control system is an advanced microprocessor based system that is very easy to use.

Shubham Industrial RO Plants are available in flowrates from 0.25 M3hr. to 100 M3hr. Using high quality 4 and 8 inch semipermeable membrane and equipment’s for variety of applications.

Working Principal of Ro Plant

Industrial RO Plant is water purification process in which pre-treated & filtered water is connected to the high-pressure pump where pressure is developed and fed to the RO membranes.Reverse Osmosis membranes work on the Cross flow Filtration method where the salts get rejected partially and deliver pure water. Purified water is referred to as product and waste water is referred to as concentrate or reject. The percent of water delivered as product is called the recovery. The ratio of recovery& output parameters depend upon the feed water quality, type of membrane, temperature and total RO unit design considerations.

Technical Specifications of RO Plant

Flow : 0.25M3/Hr. – 50 M3/Hr.

Inlet TDS : Up to 10000 Mg/L for brackish water up to 35000 Mg/L for Sea Water

Outlet TDS : 98% Rejection

Flux Rate : Varies from 15 LMH to 30 LMH

Temperature : 25˚ Celsius

Type of Membranes : Energy efficient Polyamide

SDI : < 3 at inlet

Controls : Microprocessor / PLC

Flow Monitoring : Rota meter / digital flow meters.

Pre filters : PP & SS with 5 Micron cartridges

High Pressure Pumps : Vertical inline SS 304 & 316

Pre Filter : Cartridge Filter of 5 Micron absolute

Membranes housing : FRP / SS

RO Skid : MSEP / SS

Salient features

TFC RO Membranes ensure optimum water quality

High pressure 316 stainless steel vertical multistage feed pump

ASME Code FRP, RO pressure vessels with pressure relief protection

UPVC low pressure feed, product and reject piping, 316L stainless steel high pressure piping

Epoxy coated carbon steel / SS frames

Dry contacts are provided for chemical feed, pre-treatment equipment, storage tank levels, and pressure switches

All alarm and shut down conditions are indicated on the control interface.

Advantages of RO Plant

User-friendly programmable controls

High quality components ensure continuous, reliable operation

Pre-engineered systems mean easy installation

Clean-in-place connections maximize system availability

Compact footprint saves valuable floor space

Quick equipment delivery keeps project moving fast

Easy to install and operate.

Produces high quality Water

Variety of cost effective standard models.

Applications

Boiler water Treatment

Cooling Tower Water Treatment

Process Water

Drinking Water

Horticulture for high end crop

Dialysis

Laboratories

Water For injection (WFI)

Water for electrical conductor circuits

Wastewater recycling

Zero Liquid discharge system

Industrial ro plant in ahmedabad from Shubham Hydrosys Pvt. Ltd

For More Information Log on to us : Shubhamindia.com
